Chapter 4 Designing Labels with LDS

438 Operator’s Manual - 880052-0100 4-19

This is a list of the first label format field element mnemonics for the sample label in Figure

4-5:

TSN, XB, YB, CC, TCI, CGN, FO, FJ, CMX, CMY, CS, TSP, , , AN

1, 340, 712, , 6, , , , 600, 25, , , , , 0

Figure 4-6 Label Format Line Draw

TSN (Text String Number) The TSN parameter may point to any valid text string but it is a

good idea to always use “1” to make trouble-shooting formats easier. The text string that

the TSN is referencing must contain at least one character in order for a line to print

properly. “Line” was used in the example to clearly define the label format fields that contain

line values. However, it could have simply been one character such as a period “.”

XB (X Beginning Coordinate) The X and Y coordinates determine the start of the line

draw.

This is the

origin; 1,1

X beginning

4” PRINT HEAD

Y beginning

Feed Direction

CMX

CMY
